The third largest among Shantui’s powerful lineup of heavy-duty dozers, the SD32W is a beast that really rocks in tough working conditions such as rocky or frozen earth environments. It comes with a rock-type blade and tracks giving it the nimbleness it needs to perform with great efficiency when adapting to such harsh conditions.It is one of our best-selling models for mining uses. It comes equipped with a hydraulic drive system with hydraulic control technology and an advanced structure, which provides reliable performance and convenient and flexible operation.
Bulldozers are mainly usedfor excavating road cuts,constructing embank-ments, backfilling foundation pits, and removingobstacles etc.
The bottom edge of thebulldozer is level with thebottom edge of the track.enhancing functions suchas trenching,backfilling.and leveling.
In most operations, theefficiency of an excavatorequipped with a bulldozeris much higher than thatof an excavator withoutassembly.
This type of bulldozer hasthe advantages of hightraction and climbingability,making it capableof handling more danger-ous working environments.
Wheeled bulldozers offer high productivity as well as excellent maneuverability and versatility. Designed for demanding operations, these practical machines are ideal for a wide range of applications such as surface mining, clearing, stockpiling, road maintenance, reclamation, and operations requiring travel between multiple sites.
|
Classification:
|
crawler bulldozer
|
|
brand:
|
Shantui
|
|
Engine power:
|
162kw
|
|
Engine brand:
|
Cummins
|
|
engine model:
|
NT855-C280 (S10)
|
|
Rated engine speed:
|
1800r/min
|
|
Engine maximum torque:
|
1030N.m
|
|
Engine fuel consumption rate:
|
205g/kW.h
|
|
Engine Fuel Tank Capacity:
|
450L
|
|
engine capacity:
|
14.010L
|
|
The quality of the whole machine:
|
23450kg
|
|
Dozer Blade Width:
|
3725mm
|
|
Dozer Blade Height:
|
1315mm
|
|
Dozer blade capacity:
|
6.4m³
|
|
Maximum cutting depth of bulldozing blade:
|
540mm
|
|
Maximum inclination of bulldozing blade:
|
735mm
|
|
Maximum Width of Ripper:
|
2000mm
|
|
Minimum turning radius:
|
3300mm
|
|
Forward I gear speed:
|
3.6km/h
|
|
Forward second gear speed:
|
6.5km/h
|
|
Forward Ⅲ gear speed:
|
11.2km/h
|
|
Reverse Ⅰ gear speed:
|
4.3km/h
|
|
Reverse second gear speed:
|
7.7km/h
|
|
Reverse Ⅲ gear speed:
|
13.2km/h
|
|
Track sprocket pitch:
|
216mm
|
|
Track ground length:
|
2730mm
|
|
Track center distance/gauge:
|
2000mm
|
|
Number of carrier sprockets (per side):
|
2
|
|
Number of rollers (per side):
|
6
|
|
Ground specific pressure:
|
77kPa
|
|
Minimum ground clearance:
|
405mm
|
|
Gradeability:
|
30°
|
|
Hydraulic pump model:
|
262
|
|
Hydraulic system rated pressure:
|
14Mpa
|
|
Number of bulldozer cylinders*bore*stroke:
|
2*120mm
|
|
Water tank capacity:
|
79L
|
|
Vehicle length:
|
5460mm
|
|
Vehicle width:
|
3725mm
|
|
Vehicle height:
|
3395mm
|
