The price of Mini Crane Truck With 8 Ton Crane , Crane Machine With Iso Certificate from China is based on the bulk order quantity. Henan Zlin Construction Machinery Sales Service offers flexible prices for Other Construction Machinery variations depending on the importing country and quantity.
The advantages of Crane Truck in general are:
1. Ease of movement. With its lifting performance and appearance of the size of the conditions, can be lifted to accept the lifting of most of the factory or workshop lifting work.
2. without overhead tracks and other fixed structures, but also to reduce the infrastructure of some unnecessary investment and production costs and maintenance costs.
3. There are unique power supply devices, without the installation of feeder wires and contact with conductive equipment.
|
Item
|
project
|
Unit
|
Specification
|
|
t
|
8
|
||
|
performance specification
|
Maximum lifting moment
|
KN.m
|
320
|
|
Full extension arm*lift height
|
m
|
33
|
|
|
Full extension arm + jib maximum lifting height
|
m
|
33
|
|
|
mass specification
|
total mass
|
kg
|
16000
|
|
driving specification
|
maximum speed
|
km/h
|
90
|
|
*±1® slope
|
%
|
30
|
|
|
External shape size (length X Yao X height)
|
mm
|
10470x2400x3380
|
|
|
Longitudinal span of outrigger
|
mm
|
5000
|
|
|
Horizontal span of outriggers
|
mm
|
5400
|
|
|
upper body specification
|
The main arm is fully extended
|
mm
|
8400/30650
|
|
jib length
|
mm
|
none
|
|
|
Fuel tank capacity
|
L
|
280
|
|
|
Radius of gyration
|
mm
|
2550
|
|
|
Windlass Bear (Swiss IJ)
|
m/min
|
125/140
|
|
|
Number
|
EQ1160GL6DJ1
|
||
|
engine model
|
YCS04180-68
|
||
|
engine power
|
KW
|
132
|
|
|
chassis specificiation
|
Typical box model
|
SC8JS85E/ 8 forward
|
|
|
Cylindrical lattice
|
9.00R20-16PR
|
||
|
fuel tank volume
|
L
|
160
|
|
|
wheelbase
|
mm
|
4200
|
Strictly follow nationalstandards to producelifting performance thatreaches 1.25 times thelifting coefficient.
Adopting Dongfengseries mature chassis.with mature and reliabletechnology, and nation-wide after-sales service
Adopting a Yuchai inter-cooled turbocharged fourcylinder diesel engine, theemissions comply with thenational VI standard.
More humanized con-figurations,people-oriented detailsdetermine quality
