The optimizing layout of the machine makes the stress of the main bearing carriers more reasonable, and the lifting performance is higher than the products with the same tonnage.
The advantages of Crane Truck in general are:
1. Ease of movement. With its lifting performance and appearance of the size of the conditions, can be lifted to accept the lifting of most of the factory or workshop lifting work.
2. without overhead tracks and other fixed structures, but also to reduce the infrastructure of some unnecessary investment and production costs and maintenance costs.
3. There are unique power supply devices, without the installation of feeder wires and contact with conductive equipment.
|
parameter item
|
Unit
|
Specification
|
|
Size parameters
|
||
|
Overall length
|
mm
|
14170
|
|
Machine full width
|
mm
|
2800
|
|
Overall height
|
mm
|
3640
|
|
wheelbase
|
mm
|
1470+4400+1350
|
|
wheelbase
|
mm
|
2322/2063
|
|
Self-disassembling balance weight mass
|
kg
|
9500
|
|
Dynamic parameters
|
||
|
engine model
|
1、D10.38-50 2、MC11.36-60
|
|
|
engine rated power
|
kw/(r/min
|
1、276/2000 2、268/1900
|
|
Driving parameters
|
||
|
top speed
|
km/h
|
≥90
|
|
Minimum stable driving speed
|
km/h
|
|
|
Maximum grade
|
％
|
≥45
|
|
approach angle
|
°
|
21
|
|
departure angle
|
°
|
15
|
|
vertical
|
m
|
6.1
|
|
Horizontal
|
m
|
7.5
|
|
basic arm
|
m
|
11.6
|
