LTS212H Road Roller

This machine is the ideal equipment for foundation compaction in highway, mining road, large dam, important harbor and industrial site.

Chat [email protected] Inquiry

PRODUCT ADVANTAGES

LTS212 Road Roller is a fully hydraulic vibratory road roller produced by adopting foreign advanced technology and imported key components. This machine is a super heavy vibratory roller with large working mass and strong excitation force, thus it is the best compaction equipment for large area, high quality, high efficiency and mechanized construction.

It is suitable for compacting non-cohesive materials, such as gravel, crushed stone, sand and gravel mixture, sandy soil, etc. It also has good compaction effect on the substrate material.

Wild Applications of Road Roller

The roller can work flexibly in the narrow construction area, mainly used for ditch foundation, road, sports ground compaction leveling, can also be used for compaction of asphalt surface operation, the machine is good to the edge, making the compaction operation more rigorous and refined.

Equipped with export-standard brand-name power, strong horsepower, making the roller in the compaction operation performance is more stable, can be a long time continuous operation, compaction efficiency is high, easy for construction workers to catch up with the progress of the project, effectively shorten the construction period, there will be no delay in the phenomenon of the construction period.

Technical Parameters

MODEL
LTS212H
Operating mass
kg
12000
Static linear load
N/cm
300
Vibration amplitude
mm
1.7/0.8
Vibration frequency
Hz
28/35
Centrifugal force
kN
260/160
Travel speed
km/h
11
Grade ability
%
30
Turning radius
mm
6500
Overall dimension
mm
5820x2278x3050
Vibration round width
mm
2100
Wheelbase
mm
3160
Ground clearance
mm
472
Diesel power
kw
110
Diesel model
6BT5.9

Vehicle Details

LTS212 Road roller
Main Features
1.Motor:cummins6BTA5.9 extra-pressure diesel engine,have power man coffeciency,which comply with the operating condition above 4000 meters altitude.
2.Total hydraulic pressure,single drive,frequency and radiation conversion,articulated direction change,with stepless speed changes,advanced technology;Blocking the oil supply to brake the vehicle,safe and reliable.
3.Streamiline outline,circular windshield glass and curvy hood form a unique style.
4.Hydraulic pump and vibrating motors are of the 90 series made by the American manufacturer SAUER
