FOTON G9 Mini Bus Van

The Foton View Mini Bus has a simple and elegant design with hard lines and a compact structure, which also improves the durability of the vehicle. The interior is spacious and can be flexibly configured to meet different transportation needs.

Chat [email protected] Inquiry

PRODUCT ADVANTAGES

Foton View Mini Bus is mostly used for conversion of special purpose vehicles, such as conversion of refrigerated trucks.

It is also available in a freight version of the chassis for cargo transportation, while the passenger version of the Foton View Mini Bus can be used as a commercial vehicle through interior upgrades.

With the growing maturity of the market for personalization of commercial vehicles, it is becoming easier and easier to modify a business to meet your aesthetic requirements according to your personal preferences, as long as there is enough space, you can play in this limited space unlimited possibilities.

Wild Applications of mini bus

Minibuses are small vehicles that can carry up to 10 passengers. They are often used for small group tours or transportation services. Minibuses are an excellent choice for those who need to travel short distances or do not wish to use public transportation. Mini Bus Design and Functions Mini buses are usually converted from a large van, with the bodywork modified to suit the needs of the passengers. If specially designed, they can provide additional seating and luggage storage space in a spacious interior. Some minibuses also offer passenger entertainment equipment, such as stereos and televisions, as well as comfortable seating and air-conditioning systems.

Technical Parameters

【Type】 BJ6489B1PWA-1
【 Drive system】 4×2
【Vehicle dimensions(mm)】 4840×1695×1980
Person 15
【Wheelbase】 2570
【Minimum turning radius】 5500
【Wheelbase (front / rear) (mm)】 1470/1465
【air-conditioning】 [Electric air conditioner]
【Maximum speed (km / h)】 120
【Curb weight】 1850
【Maximum total mass】 3020
【Minimum groud clearance】 160
【Front suspension / rear suspension dimensions (mm)】 1190/1080
【Fuel&Engine】
【Fuel type】 【gasoline】
【Engine model】 BJ491EQ4
 [N·m(r/min)]【Torque】 193
 [kw/ps(r/min)]
【power】
76
【Emission standard】 【EUROⅡ】
【Displacement】 2237
【Gearbox type】 ZM001A1
【Chassis】
【Tire specification】 195R15C
【Front suspension】 Double-wishbone torsion bar spring independent suspension
【Rear suspension】 Leaf spring non-independent suspension 3 + 1
【Turn to】 【Power steering】
【brake】 【Front drum】
【Rear axle rated load】 1800
【Final drive ratio】 4.875
Other basic configuration Load sensing proportional valve / Grey glass sliding window / Overseas general color bar / Front heater front and rear air conditioning / Electronic adjustable headlights + Front fog lamp / Knitted seat + Headless / Two-point seat belt / Electric door and window + Remote control lock / 2 speakers / no electronic navigation / radio / reversing radar / PVC floor covering / chrome-plated manual adjustment without defrost manual folding without turn signal rearview mirror / rear wiper + rear spray + rear defrost + rear ground mirror /0.5Kg fire extinguisher / PU steering wheel / PU shift handle / electric air conditioner / front door step / step lights / chrome-plated front grille / adjustable steering wheel / PU shift dust cover / forward driving sun visor (with bill clip) / Body-colored front and rear bumpers / chrome-plated rear-view mirrors / co-pilot visor / anti-glare interior rear-view mirrors / chrome-plated door buckle / high brake lights / 15 seats / tie rod antenna
1. Three-stage sliding window, cancel the radio; 2. Change the split air conditioner controller; reserve audio harness interface; 3. After installing the camera (overseas installation of MP5 + reversing video in overseas); 4. Retain the audio equipment mask 5. Two-point seat belt in the middle small seat; 6. The first row of three people in the passenger area is connected, the second row is 2 + 1 folded, the third row is 2 + 1 fixed, and the last row 2 is flipped +1 fixed; The three-point safety belt of the main and auxiliary drivers has a headrest.

Vehicle Details

The Foton View Mini Bus is equipped with a smooth power output, which can meet the needs of long-distance transportation and urban distribution.

The external rear-viewmirror has a large longitudinal dimension,which can provide agood field of vision for ahigher body.

2. Jingjing G9 adopts the195 R15C Jiatong tire,which is matched withsteel rims.

3. lt’s 19 inch wheel is offi-cially called LingboWindblade wheelwhichis simple and capable indesign but has a senseofmovement.

4. the four-spoke steeringwheel has a simpledesign and is equippedwith hydraulic powersteering system asstandard.
