Tire is a grounded rolling circular elastic rubber product assembled on various vehicles or machinery, usually mounted on a metal rim.
1、Support all the weight of the vehicle, bear the load of the car, and transfer the force and torque in other directions;
2、Transmit the torque of traction and braking, ensure good adhesion between wheels and road surface, in order to improve the dynamics of the car, braking and throughput;
3、It and the automobile suspension together to moderate the impact of the car driving, attenuation of vibration;
4, to prevent automotive parts and components are subject to severe vibration and early damage, to adapt to the vehicle’s high-speed performance and reduce the noise when driving.
Size | LI/SS | PR | Rim size | Rim | Inflated Section width | Overall diameter | Radius under load | Load capacity kg/lbs | IP | OTD | ||
allowance | mm | mm | mm | Single | Dual | kpa | Psi | mm | ||||
10.00R20 | 146/143L | 16 | 7.5 | 7.50V,8.00 | 278 | 1054 | 486 | 3000/6610 | 2725/6005 | 830 | 120 | 15 |
10.00R20 | 149/146L | 18 | 7.5 | 7.50V,8.00 | 278 | 1054 | 486 | 3250/7160 | 3000/6610 | 930 | 135 | 15 |
11.00R20 | 150/147L | 16 | 8 | 8.50,8.00V | 293 | 1085 | 499 | 3350/7390 | 3075/6780 | 830 | 120 | 16 |
11.00R20 | 152/149L | 18 | 8 | 8.50,8.00V | 293 | 1085 | 499 | 3550/7830 | 3250/7160 | 930 | 135 | 16 |
11.00R20 | 152/149L | 18 | 8 | 8.50,8.00V | 293 | 1085 | 499 | 3750/8270 | 3450/7610 | 830 | 120 | 17 |
11R22.5 | 144/142M | 14 | 8.25 | 7.5 | 279 | 1054 | 491 | 2800/6175 | 2650/5840 | 720 | 105 | 15 |
11R22.5 | 146/143M | 16 | 8.25 | 7.5 | 279 | 1054 | 491 | 3000/6610 | 2725/6005 | 830 | 120 | 15 |
12R22.5 | 143/141L | 12 | 9 | 8.25 | 300 | 1085 | 504 | 2725/6005 | 2575/5675 | 620 | 90 | 16 |
12R22.5 | 150/147L | 16 | 9 | 8.25 | 300 | 1085 | 504 | 3350/7390 | 3075/6780 | 830 | 120 | 16 |
12R22.5 | 152/149K | 18 | 9 | 8.25 | 300 | 1085 | 504 | 3550/7830 | 3250/7160 | 930 | 135 | 16 |
13R22.5 | 156/153L | 18 | 9.75 | 9 | 320 | 1124 | 521 | 4000/8820 | 3650/8050 | 875 | 127 | 17 |
295/80R22.5 | 152/148M | 16 | 9 | 8.25 | 298 | 1044 | 487 | 3550/7825 | 3150/6945 | 850 | 125 | 16 |
315/80R22.5 | 154/151M | 18 | 9 | 9.75 | 312 | 1076 | 500 | 3750/8270 | 3450/7610 | 830 | 120 | 17 |
315/80R22.5 | 157/154L | 20 | 9 | 9.75 | 312 | 1076 | 500 | 4125/9090 | 3750/8270 | 900 | 130 | 17 |
