HOWO NX 400HP DUMP TRUCK 6X4

HOWO NX 400HP DUMP TRUCK 6X4 is a cost-effective dump truck product launched, the vehicle adopts the concept of standardisation, modularisation and lightweighting, and the whole vehicle has better comfort, reliability and economy.

Chat [email protected] Inquiry

PRODUCT ADVANTAGES

HOWO N7 6×4 Dump Truck

1.Strong bearing capacity
2.Strong ability to reload and start
3.Cost-effective, complete procedures
4.Low failure and quality guarantee
5. This car has many configurations and models.
If you choose other configurations or models, please send an inquiry and contact the sales staff. We will configure a suitable car according to your needs and give you apreferential price.

Wild Applications of Dump Truck

General-purpose engineering dump trucks can meet the needs of non-urban earthworks and general mining vehicle use, as a road hauler use, the loading capacity and weight is not advantageous, but a variety of conditions can be involved, suitable for the use of the card users are not fixed.

Technical Parameters

Name New HOWO N7 6×4 Dump Truck
Driving model LHD/RHD (left hand drive or right hand drive)
Overall dimension 8700x2496x3350mm (Length x width x height)
Dump body Type of body ”田”
Body size 5600 x 2300 x 1500mm
Body thickness 8mm at the bottom, 6mm at both sides
Lifting system Front hydraulic system or middle hydraulic system
Cabin H77L,new face,1 bed,2 seats,A/C ,USB,radio
Tires 10+1 spare tyre with rim
12.00R20 radial tyre, 18PR, mixed pattern
Wheelbase 3800+1350mm
Axle VGD95 front axle,MCX16ZG*2 rear axle
Engine Model WP10.380E22, Euro II, Diesel
Engine power 280KW (380HP) @ 2200 tr / min
Max torque 1600 N.m @ 1500-1800 tr / min
Air intake type turbo-charge and inter-cool
Fuel injection type Direct injection

Vehicle Details

Strong fuel adaptability,suitable for African road conditions. lower maintenance and service costs ensuring lower usage costs

The gearbox adopts China National Heavy Duty Truck, HOWO series gearbox, which is high-performance and reliable in quality.

Advanced engineering technology and production base enable our axles to exhibit outstanding durability and performance.

The interior and exterior of the cab are designed by a European design team. reflecting the overall aesthetic of the vehicle, with simplicity and elegance.
