F3000 dump truck 6X4 are mainly used in construction, mining, transportation and agriculture. It is mainly used to transport construction materials or raw materials, such as transporting minerals like sand, sandstone and gravel.
F3000 dump truck 6X4 is a commonly used special vehicle for transportation because the truck can automatically dump the materials at a certain angle, which greatly saves the time and labor for unloading, shortens the transportation cycle, improves the production efficiency and reduces the transportation cost.
General-purpose engineering dump trucks can meet the needs of non-urban earthworks and general mining vehicle use, as a road hauler use, the loading capacity and weight is not advantageous, but a variety of conditions can be involved, suitable for the use of the card users are not fixed.
|
item
|
value
|
|
Steering
|
Left
|
|
Maximum Torque(Nm)
|
1500-2000Nm
|
|
Dimensions (L x W x H) (mm)
|
8800*2570*(3450 ±30)mm
|
|
Cargo Tank Dimension
|
5.8*2.3*1.5 m
|
|
Cargo Tank length
|
5.3-6.2M
|
|
Gross Vehicle Weight
|
25000kg
|
|
Capacity (Load)
|
50t
|
|
Fuel Tank Capacity
|
≤100L
|
|
Drive Wheel
|
6*4
|
|
Number Of Forward Gears
|
10
|
|
Engine
|
340HP
|
F3000 series 6X4 dump trucks, adopting special chassis of Shanxi Automobile Delong, Weichai 336 HP engine, the chassis is solid and durable, with strong power, which can meet the needs of different working conditions; the upper compartment adopts high-strength cold-rolled corrugated steel plate structure, with large loading space, high strength, strong lifting force, stiffness, good toughness, strong bearing capacity, and does not undergo permanent deformation.
.jpg)
Payload: 30-35T
Bucket: 19 CUBIC METERS
Truck Brand : SINOTRUK –HOWO
Driving Type : Left Hand Driving
Gearbox : 6 AT
Fuel tank volume : 80(L)
