Dongfeng garbage truck is widely used in urban street garbage disposal, all of them have self-unloading function and hydraulic operation, which is convenient for dumping.
Sanitation truck garbage truck is very common when dealing with long-distance garbage transportation, its characteristics are also very obvious, especially the large sanitation truck garbage truck can achieve a large amount of one-time loading and transportation, can achieve compression, after sealed transportation, can better prevent secondary pollution, suitable for long-distance transportation of garbage. Sanitation truck garbage truck has become more and more common garbage collection vehicles. Usually stored garbage containers sanitation plastic barrels and the original iron barrels
Truck
|
Chassis model
|
EQ1070TJ9AD3
|
||
Engine
|
CY4102-C3C
|
|||
Max. power(KW/rpm)
|
88/3856
|
|||
Max. torque(N.m)
|
345
|
|||
Type OF Fuel
|
Diesel
|
|||
Outer dimension (mm)
|
7000×2320×2900
|
|||
Wheel base (mm)
|
3800
|
|||
Front/Rear tread(mm)
|
1750/1586
|
|||
F/R Axle Loading Capacity(Kg)
|
2845/4645
|
|||
Payload (kg)
|
3200
|
|||
Curb weight(kg)
|
6095
|
|||
G.V.W (kg)
|
9490
|
|||
Max Speed(Km/h)
|
95
|
|||
Tyre
|
8.25-16
|
|||
Specfication of Tank
|
Container Capacity(m³)
|
5-8
|
||
Filling Mouth Grand Clearance(mm)
|
740
|
|||
Filling Circulation Time(s)
|
20-25
|
|||
Precompressor Load Time(s)
|
18-22
|
|||
Precompressor Lifting Time(s)
|
6-9
|
|||
Max. Compression Strength(T)
|
12
|
|||
Max.Discharge Strength(T)
|
8
|
Dongfeng garbage truck has the advantages of high pressure, good sealing, convenient and reliable operation, etc. The curved box greatly increases the volume of the box as well as the aesthetics of the whole truck.
Dongfeng garbage truck has excellent material selection and strong compression capacity, strong transportation stability, good sealing between the garbage box and the rear door assembly, customized rubber strip sealing between the garbage box and the rear door assembly, good sealing, avoiding secondary pollution. All the filling and discharging operations require only one driver to operate; not only reduces the labor intensity of sanitation workers, but also greatly improves the work efficiency.
Dongfeng garbage truck has full power and solves the problem of secondary pollution during garbage transportation.
